DigiSun VH712 4K2K HDMI 1x2 Splitter
Introduction :
VH712 4K2K 1x2 HDMI splitter distributes one HDMI source to two HDMI displays simultaneously. It provides high performance audio and video output through HDMI cables up to 4K2K resolution and is capable of receiving and transmitting up to 10.2Gbps of bandwidth without data loss.
- 1 x HDMI input displays to 2 x HDMI outputs with scaler function
- Max Signal Range: 1920 x 1080 1080P; 3D 1080P @24Hz, 4K x 2K
- Protocol compatible HDMI 1.4 & HDCP1.2
- Supporting 480i/480P@60Hz, 576i/576P@50Hz, 720P@50/60Hz, 1080i@50/60Hz, 1080P@50/60Hz, 720P@50/60Hz 3D, 1080P/24Hz 3D, 4Kx2K
- Compatible blue-ray, PS3 media format, Fully support 3D display.
- Operating Frequency: Up to 10.2GHz
- ESD protection:EC61000-4-2s
Connection Image :
Specification：
| I/O HDMI ports |
1 input, 2 output |
| Max Signal Range |
1920 x 1080 1080P; 3D 1080P @24HZ, 4K x 2K |
| HDMI Resolution |
480i/480P@60Hz, 576i/576P@50Hz, 720P@50/60Hz, 1080i@50/60Hz, 1080P@50/60Hz, 720P@50/60Hz 3D, 1080P/24Hz 3D, 4Kx2K
|
| Bandwidth |
10.2 GHz |
| Protocol |
4K2K HDMI 1.4 & HDCP 1.2 (Compatible HDMI 1.3/1.2/1.1/1.0) |
| Video Color Format |
24 / 30 / 36(bit) deep color |
| Audio Format |
DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dolby-AC3/DSD |
| ESD Protection Protocol |
IEC61000-4-2s |
| Transmission Length |
Input 30m
Output 25m
|
| Power Supply |
DC 5V / 1A |
| Dimension |
96 x 59 x 17 mm 98 g |
Package Contents：
1 x VH712 4K2K HDMI 1x2 Splitter
1 x User Manual
1 x Power Adaptor
|
